TO252封装系列产品

概览产品型号

概览

镭诺电子提供的N型12V~200V和P型12V~150V 沟槽型（Trench）功率MOSFET 产品，采用先进的工

艺制造技术、更优的工艺条件、精细优化的器件结构不断优化产品导通电阻、开关特性、可靠性等并

持续推进产品迭代，以丰富的产品系列、业内先进的参数性能与优异的可靠性成为行业标杆。产品广

泛应用于电机驱动、电池管理系统、负载开关、通信、消费电子等各个领域。同时提供丰富的封装外

形供客户选择，包括DFN1*1、DFN2*2、DFN3.3*3.3、DFN5*6、SOT-23、SOT-523、SOT-89、

SOT-223、SOP-8、TO-251、TO-252、TO-220、TO-263、TOLL、TO-247等。

产品型号

注：因产品更新太快，产品用户手册有多个版本，如您需要最新版本的用户手册，请联系王先生（15560230695微信同号）咨询。

Product No	PlatForm	Package Type	Configuration	Polarity	BV(V)	ID(A)	VGS (V)	Vth (V)	RDS(ON)@ 10VTyp （mΩ)	RDS(ON)@ 4.5VTyp （mΩ)	Qg (nC)Typ
Reset	SGT Trench Reset	PDFN56 PDFN3.33.3 LFPAK56 STOLL TO220 TO252 TO263 TO263-7 TOLL-8L SOP-8 TSSOP-8 PDFN88 TO247 TOLT SOT23-3L TO247 Reset	Single Asymmetric Complementary Dual Reset	N N+P N+N P P+P Reset	Reset OK	Reset OK	±10 ±12 ±20 ±25 Reset	Reset OK	Reset OK	Reset OK	Reset OK

LN068N020J	Trench	TO252	Single	N	20	50	±12	0.5-1		6.8	16
LN018N030JF	SGT	TO252	Single	N	30	80	±20	1.5	1.8	2.5	53
LN025N030J	Trench	TO252	Single	N	30	150	±20	1.5	2.5	3.3	120
LN030N030J	Trench	TO252	Single	N	30	90	±20	1.5	3	4.5	65
LN018N030J	Trench	TO252	Single	N	30	105	±20	1.5	1.8	2.6	103
LN022N030J	Trench	TO252	Single	N	30	105	±20	1.5	2.2	3.5	85
LN100N030J	Trench	TO252	Single	N	30	30	±20	1.5	10	14	22
LN066N030J	Trench	TO252	Single	N	30	50	±20	1.5	6.6	10.5	23
LN035N030J	SGT	TO252	Single	N	30	80	±20	1.5	3.5	5.5	20
LN070N040J	SGT	TO252	Single	N	40	60	±20	1.5	7.0	12.5	15
LN021N040J	SGT	TO252	Single	N	40	80	±20	1.8	2.1	3.0	49
LN045N040J	Trench	TO252	Single	N	40	90	±20	1.5	4.5	6	61
LN041N040J	SGT	TO252	Single	N	40	75	±20	1.5	4.1	6.2	21
LN024N040J	SGT	TO252	Single	N	40	100	±20	1.5	2.35	3.28	53
LN030N040J	Trench	TO252	Single	N	40	160	±20	1.5	3	6.5	100
LN070N045J	SGT	TO252	Single	N	45	40	±20	1.5	7	11.5	14
LN031N045J	SGT	TO252	Single	N	45	80	±20	1.5	3.1	4.2	48
LN027N060J	SGT	TO252	Single	N	60	100	±20	2	2.7	4.6	87
LN046N060J-L	SGT	TO252	Single	N	60	60	±20	1.5	4.6	6.5	40
LN046N060JF	SGT	TO252	Single	N	60	60	±20	3	4.6		34
LN070N060J	SGT	TO252	Single	N	60	65	±20	2	7	11	27
LN076N060J	SGT	TO252	Single	N	60	65	±20	3	7.6		26
LN120N060J	SGT	TO252	Single	N	60	50	±20	2	12	22	15
LN070N060J	Trench	TO252	Single	N	60	80	±20	3	7		90
LN125N060J	Trench	TO252	Single	N	60	50	±20	1.5	12.5	16	48
LN195N060J	Trench	TO252	Single	N	60	45	±20	1.5	19.5	23.5	27
LN260N060J	Trench	TO252	Single	N	60	30	±20	1.5	26	31	19
LN750N060J	Trench	TO252	Single	N	60	15	±20	1.5	75	80	12
LN450N060J	Trench	TO252	Single	N	60	25	±20	1.5	45	58	12
LN077N080J	SGT	TO252	Single	N	80	50	±20	2	7.7	11.7	34
LN145N085J	SGT	TO252	Single	N	85	55	±20	1.8	14.5	20.5	34
LN048N085J-L	SGT	TO252	Single	N	85	100	±20	1.7	4.8	6.3	67
LN048N085J	SGT	TO252	Single	N	85	100	±20	3	4.8		64
LN041N085J	SGT	TO252	Single	N	85	120	±20	3	4.1		80
LN030N100J	SGT	TO252	Single	N	100	100	±20	2	3		105
LN050N100J	SGT	TO252	Single	N	100	100	±20	2	5	7	59
LN045N100J	SGT	TO252	Single	N	100	100	±20	2	4.5	8.6	64
LN055N100J	SGT	TO252	Single	N	100	60	±20	2	5.5	7.9	62
LN105N100J	SGT	TO252	Single	N	100	50	±20	2	10.5	16	25
LN1K2N060SA	Trench	TO252	Single	N	60	1	±20	1	1		1
LN680P150J		TO252		P	-150	-30	±20				0
LN1R80P100J	Trench	TO252		P	-100	-20	±20				0
LN015N040J-H	SGT	TO252	Single	N	400	180		3	1.5		77
LN060N100J	SGT	TO252	Single	N	100	70	±20	1.8	6.0	8.0	65
LN600N200J	Trench	TO252	Single	N	200	20	±20	3	10		21
LN3R88N200J	SGT	TO252	Single	N	200	6	±20	3	3		5
LN1R40P150	Trench	TO252	Single	P	-150	-15	±20	-2.0	-12		55
LN10K0P100SA	Trench	SOT23-3L	Single	P	-100	0	±20	-2.0	0.1	0.1	2
LN4K5N100SA	Trench	SOT23-3L	Single	N	100	1	±20	2.5	0.2	0.1	1
LN070N045J	SGT	TO252	Single	N	45	40	±20	1.2	10	5	15
LN075N100J	SGT	TO252	Single	N	100	60	±20	3	7.5		45
LN180N100J	SGT	TO252	Single	N	100	30	±20	1.7	18	26	22
LN150N100J	SGT	TO252	Single	N	100	30	±20	1.7	15	21	26
LN100N100J-L	SGT	TO252	Single	N	100	50	±20	1.7	10	14	25
LN100N100J	SGT	TO252	Single	N	100	50	±20	3	10		25
LN130N100J-L	SGT	TO252	Single	N	100	50	±20	1.8	13	17	25
LN130N100J	SGT	TO252	Single	N	100	50	±20	3	13	17	25
LN750N100J	Trench	TO252	Single	N	100	15	±20	1.5	75	80	27
LN850N100J	SGT	TO252	Single	N	100	10	±20	1.5	86	115	5
LN215N120J	SGT	TO252	Single	N	120	30	±20	2	21.5	26.5	22
LN200N150J	SGT	TO252	Single	N	150	40	±25	3	20		34
LN490N150J	SGT	TO252	Single	N	150	21	±25	3	49		16
LN2R95N150J	SGT	TO252	Single	N	150	5	±25	1.5	295	335	4
LN060P020J	Trench	TO252	Single	P	-20	-50	±12	-0.7	6	7	60
LN025P030J	Trench	TO252	Single	P	-30	-120	±20	-1.5	2.5	4.2	212
LN037P030J	Trench	TO252	Single	P	-30	-90	±20	-1.5	3.7	5.3	146
LN055P030J	Trench	TO252	Single	P	-30	-70	±20	-1.5	5.5	8.5	106
LN150P030J	Trench	TO252	Single	P	-30	-50	±20	-1.5	15	25	31
LN080P030J	Trench	TO252	Single	P	-30	-60	±20	-1.5	8	12	36
LN330P040J	Trench	TO252	Single	P	-40	-30	±20	-1.5	33	46	20
LN120P040J	Trench	TO252	Single	P	-40	-50	±20	-1.5	12	18	55
LN200P060J	Trench	TO252	Single	P	-60	-50	±20	-2	20	24	23
LN770P060J		TO252	Single	P	-60	-16	±20	-1.5	77	95	17
LN500P060J	Trench	TO252	Single	P	-60	-25	±20	-1.5	50	60	23
LN1R05P060J	Trench	TO252	Single	P	-60	-10	±20	-1.5	50	60	23
LN4R40P100J	Trench	TO252	Single	P	-100	-6	±20	-1.5	440	470	10
LN1R80P100J	Trench	TO252	Single	P	-100	-20	±20	-1.5	180	190	23
LN570P100J	Trench	TO252	Single	P	-100	-30	±20	-1.5	57	63	73
LN1R40P150J	Trench	TO252	Single	P	-150	-15	±20	-2.5	140		55
LNS018N030F	SGT	TO252	Single	N	30	80	±20	1.5	1.8	2.5	53
LNT018N030J	Trench	TO252	Single	N	30	105	±20	1.5	2.1	3.3	103
LN800N100J	Trench	TO252	Single	N	100	15	±20	1.75	90		16
LN055P060J	Trench	TO252	Single	P	-60	-100	±20	-1.5	6.5	8.5	222
LN750P100J	Trench	TO252	Single	P	-100	-30	±20	-2	85	96	55
LN150P150J	Trench	TO252	Single	P	-150	-15	±20	-2	160		55
